LLT 12pin High Quality Led Strip Plug M16 IP67 Waterproof Wire Cable Data Connector

Name: LLT 12pin High Quality Led Strip Plug M16 IP67 Waterproof Wire Cable Data Connector
Brand: Shenzhen LLT Connector Co., Ltd.
SKU: LLT-M16-05012F3054

LLT 12pin High Quality Led Strip Plug M16 IP67 Waterproof Wire Cable Data Connector is a published reference for industrial ethernet links in outdoor or washdown-prone equipment. The visible configuration highlights sealing around IP65/IP67, 5A current range, 12pin pin layout, 2-12pin/2+2/2+3/2+4/3+3/2+8pin interface. Termination direction is by molding, which should be checked against the actual harness build.

Waterproof Data Connector M16 Threaded Model: LLT-M16-05012F3054

M16 / Threaded LLT 12pin High Quality Led Strip Plug M16 IP67 Waterproof Wire Cable Data Connector

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

The M16-12pin molded data cable connector is an integrated overmolded circular interconnect built to DIN EN61076-2-106 standards, specially engineered for multi-channel data and low-power signal transmission. Different from field-assembled types, its one-piece PVC/PUR injection molding eliminates loose wiring gaps for superior sealing and structural stability. Equipped with 12 gold-plated brass contacts, the component features threaded M16 locking for anti-vibration interlock. Standard IP67 ingress protection safeguards internal data circuits against dust, splash water and industrial moisture. Rated at 60V, 5A per pin, it accommodates fixed outer-diameter molded cables ranging 3mm–8mm, with customizable cable length from 0.3m to 50m and straight/right-angle plug options. Shielded molded variants with full metal housing are available to restrain EMI interference and guarantee stable high-speed data transmission. With working temperature spanning -40℃~+85℃ and over 500 reliable mating cycles, this molded data cord is widely adopted for industrial sensors, machine vision equipment, servo control modules, automation instrumentation and new-energy data collection wiring. Pre-molded finished cables save on-site assembly time and improve installation efficiency.

Application Fit

Typical application directions

Industrial Ethernet links in outdoor or washdown-prone equipment
Control cabinets, gateways, and monitoring nodes that need ingress protection
Projects targeting IP65/IP67 sealing performance and repeatable field mating.
Applications that need a connector architecture aligned with 5A current requirements.
