M16 2+3pin composed power signal Data male female assembly connector

M16 2+3pin composed power signal Data male female assembly connector is a published reference for industrial ethernet links in outdoor or washdown-prone equipment. The visible configuration highlights sealing around IP67/IP68, 10A+5A current range, 2+3pin pin layout, 2-12pin/2+2/2+3/2+4/3+3/2+8pin interface. Termination direction is soldering, which should be checked against the actual harness build.

Data Connector M16 Threaded Model: LLT-M16-15203F1051
M16 / Threaded M16 2+3pin composed power signal Data male female assembly connector

Connector Gallery

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Product Size

M16

Pin

2+3pin

IP Rating

IP67/IP68

Rated Current

10A+5A

Rated Voltage

300V

Product Series

M16

Wiring Type

Soldering

Interface Type

2-12pin/2+2/2+3/2+4/3+3/2+8pin

Mating Cycles

>=2000

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

The M16 2+3 is a 5-pin (2 power + 3 signal) circular connector designed for hybrid power/signal transmission in industrial environments. Key Features • 2+3 pin configuration: 2 high-current power contacts + 3 signal contacts, all-in-one connection. • IP67/IP68 protection: Dust-tight, waterproof, resistant to vibration and harsh conditions. • Robust construction: ◦ Housing: gold-plated copper and PA66 nylon. ◦ Contacts: Gold-plated brass (low resistance, anti-oxidation). • Electrical ratings: ◦ Power pins: 300V, 10A ◦ Signal pins: 300V, 5A ◦ Insulation resistance: ≥1000MΩ • Temperature range: -40°C to +85°C (up to +105°C available). • Termination: Solder, or field-wireable; panel/cable mount. Applications • Industrial automation (sensors + actuators) • LED lighting & outdoor displays • Robotics & machinery • Test equipment & power/signal hybrid devices Benefits • Space-saving: Combines power and signal in one connector. • Cost-effective: Reduces cabling and assembly time. • Secure connection: Screw-lock design ensures vibration resistance. • Wide compatibility: Meets IEC 61076-2-106 standards.
