LLT Factory 2+3 Pin M16 Led Lamp Cable Joiner Power Plus signal Circular Ac Dc Waterproof Cable Connector

LLT Factory 2+3 Pin M16 Led Lamp Cable Joiner Power Plus signal Circular Ac Dc Waterproof Cable Connector is a published reference for energy storage cabinets, battery systems, and inverter platforms. The visible configuration highlights sealing around IP65/IP67, 15A+5A current range, 2+3 Pin pin layout, 2-12pin/2+2/2+3/2+4/3+3/2+8pin interface. Termination direction is by molding, which should be checked against the actual harness build.

Data Connector M16 Threaded Model: LLT-M16-15203F3054
M16 / Threaded LLT Factory 2+3 Pin M16 Led Lamp Cable Joiner Power Plus signal Circular Ac Dc Waterproof Cable Connector

Connector Gallery

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Product Size

M16

Pin

2+3 Pin

IP Rating

IP65/IP67

Rated Current

15A+5A

Rated Voltage

300V+60V

Product Series

M16

Wiring Type

By molding

Interface Type

2-12pin/2+2/2+3/2+4/3+3/2+8pin

Mating Cycles

>=2000

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

M16 2+3Pin Power & Signal Hybrid Molded Cable Connector This M16 2+3pin hybrid circular connector combines 2 large power contacts + 3 small signal pins in one housing, manufactured in accordance with DIN EN61076-2-106 industrial standard. The integrated molded cable structure adopts one-step PUR/PVC overmolding to realize seamless sealing, rated IP67 for dustproof and splash-proof performance. Two oversized power terminals carry high-current power supply, while three fine gold-plated contacts transmit control signals synchronously, realizing power and signal integrated wiring to reduce cable quantity and installation space. Nickel-plated metal shell with M16 threaded lock effectively resists vibration loosening in harsh working conditions. Electrical specs: Power pins up to 8A, signal pins 3A, rated voltage 250V; applicable cable OD 4~9mm, operating temperature -40℃~+85℃, straight/right-angle plug optional, shielded version available for anti-EMI. Widely used for servo small motors, automation actuators, proximity sensors, conveyor equipment and new energy module connecting.
