LLT M8 2pin metal front panel signal data cableconnector

LLT M8 2pin metal front panel signal data cableconnector is a published reference for industrial ethernet links in outdoor or washdown-prone equipment. The visible configuration highlights sealing around IP65/IP67, 5A current range, 2pin pin layout, 2-5pin interface. Termination direction is by solder, which should be checked against the actual harness build.

Data Connector M8 Threaded Model: LLT-M8-05002M2801
M8 / Threaded LLT M8 2pin metal front panel signal data cableconnector

Connector Gallery

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Product Size

M8

Pin

2pin

IP Rating

IP65/IP67

Rated Current

5A

Rated Voltage

110V

Product Series

M8

Wiring Type

by Solder

Interface Type

2-5pin

Mating Cycles

>=2000

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

1. Product Overview This M8 2-pin metal front panel mount connector is a compact, industrial-grade circular connector designed for front-side panel installation. Adopting nickel-plated brass metal housing and screw locking structure, it provides high mechanical strength, anti-corrosion performance and stable connection in harsh industrial environments. Widely used for industrial sensors, automation equipment, instrumentation, low-power signal and power transmission systems. 2. General Specifications • Product Model: M8-2Pin Front Panel Connector • Connector Type: Circular Panel Mount Socket • Mounting Method: Front Panel Mount (Front-installed) • Locking Mechanism: Screw Locking • Number of Pins: 2 Contacts • Compliance Standard: IEC 61076-2-104 3. Electrical Characteristics • Rated Current: 5A (25℃) • Rated Voltage: 110V AC • Withstand Voltage: 1500V AC (60s) • Insulation Resistance: ≥1000MΩ • Contact Resistance: ≤5mΩ • Frequency Range: Low frequency signal & power transmission 4. Mechanical Properties • Housing Material: Brass with gold plating • Contact Material: Copper alloy with gold plating • Insulator Material: High-performance TPU • Sealing Material: O-ring • Mating Cycles: ≥2000 times • Vibration Resistance: Compliant with IEC 60512-6 5. Environmental Performance • Ingress Protection: IP67 (fully mated condition) • Operating Temperature: -40℃ ~ +105℃ • Storage Temperature: -45℃ ~ +105℃ • Pollution Degree: Level 3 6. Wiring Definition • Pin 1: Power / Signal Positive • Pin 2: GND / Signal Negative 7. Features & Advantages 1. sturdy and durable 2. Front panel mounting design, easy and fast installation 3. IP67 waterproof, dustproof and moistureproof for industrial scenes 4. Gold-plated contacts ensure stable conductivity and oxidation resistance 5. Screw locking design prevents loose connection from vibration 6. Compact size, suitable for narrow installation space 8. Application Fields • Industrial automation sensors • Mechanical equipment signal transmission • Smart instrument and meter equipment • Low-voltage industrial power connection • Outdoor monitoring and control devices • Greenhouse & horticulture lighting auxiliary wiring 9. Packaging & Certification • Packaging: Standard neutral carton packaging • Certification: CE, REACH compliant • Customization: Wire length, pin definition and logo customizable
