LLT Waterproof Connector M12 IP67 3 Pin Field Assembly Male and Female Plug Connector

Name: LLT Waterproof Connector M12 IP67 3 Pin Field Assembly Male and Female Plug Connector
Brand: Shenzhen LLT Connector Co., Ltd.
SKU: LLT-M12-10003M1031

LLT Waterproof Connector M12 IP67 3 Pin Field Assembly Male and Female Plug Connector is a published reference for cable-to-cable transitions in outdoor and industrial equipment. The visible configuration highlights sealing around IP68, 10A current range, 2-12 pin layout.

Waterproof Circular Connectors M12 Push-Lock Model: LLT-M12-10003M1031

M12 / Push-Lock LLT Waterproof Connector M12 IP67 3 Pin Field Assembly Male and Female Plug Connector

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: HannahHe

Please share your project requirement and quantity for quotation.

Technical Specs

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

Description: IP68 Rated: Superior protection against dust and water immersion, ideal for outdoor LED lighting applications. Versatile Pin Options: Available in 2, 3, 4, and 5 pin configurations to suit various power and signal requirements. Wide Operating Temperature: Performs reliably from -10℃ to 60℃, perfect for diverse environmental conditions. Gold-Plated Copper Conductors: Ensures excellent conductivity and corrosion resistance for long-lasting performance. Nylon PA66 Construction: Offers durability and resistance to environmental factors. CE, RoHS, and ISO9001 Certified: Guarantees quality and compliance with international standards. Features: Waterproof rating: IP68 Connector type: Male and Female Pin options: 2-8 pins Voltage range: 24-110V Current rating: 10A (2-3 pin), 5A (4-8 pin) Contact resistance: <10mΩ Insulation resistance: 100MΩ Cable specifications: 0.2mm² to 1mm² Cable range: max.6.1mm Applications: Outdoor LED lighting systems Landscape illumination Architectural lighting Marine lighting installations Industrial electrical connections

Application Fit

Typical application directions

Outdoor automation modules, lighting systems, and distributed control boxes
Machine-mounted cable interfaces exposed to vibration, spray, dust, or washdown
Projects targeting IP68 sealing performance and repeatable field mating.
Applications that need a connector architecture aligned with 10A current requirements.
