LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector

Name: LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector
Brand: Shenzhen LLT Connector Co., Ltd.
SKU: LLT-M12-10004F3034

LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector is a published reference for cable-to-cable transitions in outdoor and industrial equipment. The visible configuration highlights sealing around IP65/IP67, 10A current range, 4pin pin layout, 2 to 8pin interface. Termination direction is by molding, which should be checked against the actual harness build.

Waterproof Male Female Connector M12 Push-Lock Model: LLT-M12-10004F3034

M12 / Push-Lock LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector

Request Product Contact

Reveal the sales contact linked to this product page for quotation and technical discussion.

Publisher: TonyTang

Please share your project requirement and quantity for quotation.

Technical Specs

Complies with product certification:

UL TUV CQC CE RoHS REACH

System certification:

IATF 16949 ISO 13485 ISO 9001 ISO 14001 ISO 50001 ISO 45001

Product Overview

Connector application and structure details

The M12-4pin circular cable connector is a widely used industrial connector standardized to IEC 61076-2-101, designed for reliable signal and power transmission in automation and machinery systems. It features a 12mm threaded locking structure, ensuring stable connection under vibration and mechanical stress. With 4 gold‑plated contacts, it provides low contact resistance, high conductivity, and long service life. Most models offer IP67 or higher protection, making them waterproof, dustproof, and suitable for harsh industrial environments. Special 4 pin layout mis‑insertion, this connector is mainly used for sensors, actuators, PLC modules, and field bus connections. It supports flexible cable assembly with PVC or PUR jackets, offering good resistance to oil, abrasion, and temperature changes. Compact, durable, and highly compatible, the M12-4pin circular connector is a standard solution for stable and efficient industrial wiring.

Application Fit

Typical application directions

Energy storage cabinets, battery systems, and inverter platforms
Power distribution interfaces in outdoor electrical equipment
Projects targeting IP65/IP67 sealing performance and repeatable field mating.
Applications that need a connector architecture aligned with 10A current requirements.

Technical Resources

Catalog and supporting references

LLT Connector Master Catalog Overview catalog for core connector families and manufacturing capability. Miniature Power and Signal Connectors Reference for compact circular connector families and mixed power-signal layouts. Complex Multi-Branch Harness Management Harness and branch-management support for cable-ready projects.

Visual Gallery

Product details, interface geometry, and cable integration views

LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector gallery image 1

LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector gallery image 2

LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector gallery image 3

LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector gallery image 4

LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector gallery image 5

LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector gallery image 6

Compare nearby references in this family

Related Families

Move up to adjacent category pages

Waterproof Cable Connector 12 published products Pre-branched Connector 9 published products Waterproof Plug Socket 9 published products Waterproof Wire Connectors 5 published products

Technical FAQ

What should be confirmed before selecting LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector?

Confirm the sealing target, panel or cable interface, electrical load, and maintenance method together. LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector is currently configured around 2 to 8pin interface direction, so the enclosure fit and mating environment should be checked before final approval.

Which technical details matter most for this model?

Ingress protection in the current profile is listed as IP65/IP67. Rated current references include 10A. Review pin layout, termination method, cable OD, and lock structure together rather than choosing only by shell size or model name.

Can LLT support related cable assembly or customized integration for LLT M12 Electrical 4 Pin Ip68 Circular Automotive Quick Ruound Cable Connector?

Yes. LLT can discuss cable exit direction, overmolding, harness routing, and adjacent product alternatives when this model is part of a wider equipment interface or custom assembly project.

Need a quote, sample review, or cable-assembly discussion?

Share your sealing target, electrical range, enclosure interface, and cable constraints. LLT can help compare this model with adjacent options and plan the next engineering step.
